P10
IF 1 and 3 on, it is 1+4=5, it means to use the Channel 5 of the DMX controller to be the CH1 of a special lights,
then the next channel 6 of the DMX controller as the CH2 to control the lights, and so on.
IF 4 and 5 on, it is 8+16=24, it means to use the Channel 24 of the DMX controller to be the CH1 of a special
lights, then the next channel 25 of the DMX controller as the CH2 to control the lights, and so on.
(Note: some of the DMX controller provide less than 512 channels, some DMX controller provide more than 1240
channels. This depends on different DMX controller.)
