• Leave 7cm to 10cm around the receiver to ensure that proper ventilation gets to the receiver.
• Do not store your receiver on its side.
•Tocleanthereceiver,useadry,cleansoftclothwithnocleaningsolventorabrasiveproducts.Cleantheventilationopenings
regularly .
Remote Control Unit
Your remote control is specifically designed to be used with your receiver and it requires batteries. The batteries
(battery pack or batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
Replace the batteries as follows:
• Remove the battery cover by pushing the catch and sliding the cover away.
• Carefully remove the old batteries.
• Put the new batteries in, matching the marks + and -.
•Put the cover back on, sliding the top part in and making sure the catch clicks in to place.
Caution
Do not mix batteries or keep them in the remote control for long periods of time without use.
Environmental Information
The batteries use some hazardous substances which are very polluting for the environment. Do not throw them out.
Limiting the Human Body Exposure to the Electromagnetic Fields
Under normal use condition the user shall keep at least 20cm distance from the equipement.
Technical specifications
Operating voltage 100-120 VAC ~ 50/60 Hz
Typical Power consumption < 18W max
Weight 0.431 kg
Dimensions (Bigger diam x Top diam x H) 155 x 155 x 35.8 mm
Operating temperature range 0°C to +40°C
Storage temperature range -25°C to +55°C
Remote Control battery Type 2 batteries AAA 1.5V
External Power Supply
Output Voltage / Current
12V DC / 1.5 A
Set Top Box
Input Voltage / Current
12V DC / 1.5 A
Connections:
Front Panel description
The front panel shall a single, bicolor LED (green/red).
