English
11
Connections
(11)
FM antenna connection
FM ANT terminal
Insert the antenna
plug to be connected
all the way in.
Adhesive tape (not supplied)
FM indoor antenna
(supplied)
• Tape the antenna to a wall or column at the
position with the least amount of interference.
• The interference may occur if any electronic
devices are nearby.
AM loop antenna connection
AM loop antenna
(supplied)
AM ANT LOOP terminal
Push
How to assemble
1
Fold
2
Insert
3
Clicks!
• Install the antenna at the position with the
least amount of interference.
AC power supply cord
connection
Connect only after all other connections are
completed.
AC IN terminal
To a household AC
outlet
• Use only the supplied AC power supply cord.
• Insert the plugs of the cables to be connected
all the way in.
• Do not bend cables at sharp angles.
• Wireless LAN (Wi-Fi
®
) setting may start when
this unit is turned on. If you stop the Wi-Fi
setting, select “No” in “Wi-Fi Setup” screen.
Select “Yes” to keep the Wi-Fi setting. ( 13)
Note
• This unit consumes a small amount of AC
power ( 20) even when the unit is in standby
mode. Remove the plug from the main
electrical outlet if you will not be using the unit
for an extended period of time. Place the unit
so the plug can be easily removed.
To Next Page
