Before making the connections, switch OFF the power to the
receiver (or amplifier).
●
Check the input impedance and output power of the receiver
before making any connections. (
a
See “Speaker impedance and
allowed output” on page 12.)
●
Be sure to connect only positive (+) wires to positive (+) terminals,
and negative (–) wires to negative (–) terminals.
Connection of speaker cables
To prevent damage to circuitry never short-circuit positive (+) and
negative (–) speaker wires.
If using a commercially available 4-mm plug cable
Fully tighten the speaker terminal nut, and then insert the end of the
plug cable into the top of the nut.
B
Note
A
Note
When these speakers are connected to a receiver in order to
enjoy the Dolby Pro Logic System, be sure to set the center
mode on the receiver to the “NORMAL” setting.
