Technics SC-C70MK2 User Manual

32
(Continued)
Setting the network from the setup
menu
1 Press [>SELECT<] to select “Chromecast
built-in”.
2 Press [SETUP].
3 Press [
], [ ] repeatedly to select
“Network” and then press [OK].
• When “Wi-Fi Menu” screen is displayed, press
[OK].
4 Press [ ], [ ] to select “On” and then
press [OK]. (The wireless LAN function
is enabled.)
5 Press [
], [ ] to select “Wi-Fi Setup”
and then press [OK].
• “Setting” is displayed.
6 Start the “Google Home” app and
follow the on-screen instructions.
(As follows)
■
Using the “Google Home” app
“Wi-Fi Setup”
(When using the Chromecast-enabled apps with this
unit)
You can set up a connection using the “Google
Home” app.
1 Start the “Google Home” app and
follow the on-screen instructions to set
up a connection.
• When the connection is established, “Success”
is displayed.
 “Fail” may be displayed if the connection was
not complete. Try this method again from the
setup menu. If “Fail” is still displayed, try other
methods.
2 Press [OK] to exit the setting.
Note
• This unit will be displayed as “Technics-SC-
C70MK2-
****
” if the device name is not set.
(“
****
” stands for characters unique to each set.)
• You can check your network information (SSID,
MAC address and IP address) from the “Google
Home” app or “Technics Audio Center” app.
• Some items on the “Google Home” app are
irrelevant to this unit.

Technics SC-C70MK2 Specifications

General

Type	Home audio mini system
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Card reader integrated	-
Audio formats supported	AIFF, ALAC, DSD, FLAC, MP3, WAV
Digital audio optical in	1
Supported radio bands	DAB, FM
Subwoofer type	Active subwoofer
RMS rated power	30 W
Woofer diameter	80 mm
Tweeter diameter	20 mm
Number of speakers	2

Weight and Dimensions

Depth	280 mm
Width	450 mm
Height	143 mm
Weight	8000 g
