Technics SC-EH760 Service Manual

manufacturer´s specified parts shown in the parts list.
- Caution!
IC and LSI are sensitive to static electricity.
Secondary trouble can be prevented by taking care during repair.
Cover the parts boxes made of plastics with aluminum foil.
Ground the soldering iron.
Put a conductive mat on the work table.
Do not touch the legs of IC or LSI with the fingers directly.
- Voltage and signal line
: Positive voltage line
: Negative voltage line
: AM signal line
: AM OSC signal line
: FM signal line
16

Technics SC-EH760 Specifications

General

Brand	Technics
Model	SC-EH760
Category	Stereo System
Language	English
