Technics SC-EH760 Service Manual

- The marking [RTL] indicates that Retention Time is Limited for this
item. After the discontinuation of this assembly in production, the
item will continue to be available for a specific period of time. The
retention period of availability is dependent on the type of
assembly, and in accordance with the laws governing part and
product retention. After the end of this period, the assembly will no
longer be available.
- All parts are supplied by MESA.
Ref. No. Part No. Part Name & Description Pcs Remarks
1 RKM0395A-1S CABINET 1 (GC)
1 RKM0395C-S CABINET 1 (GN)
2 RHD30007-S SCREW 4
3 XTBS3+10JFZ1 SCREW 1
4 REX0967 WIRE ASS'Y 1
5 RMZ0339 ZNR COVER 1
6 RGW0343-S KNOB,VOLUME 1
7 RHN90001 NUT 1
8 RKA0106-N FOOT RING 4
9 RKF0606B-K1 BACK GRILL 1
10 RKW0581-1V FL WINDOW 1
11 RMN0427 CABLE HOLDER 1
12 RYP0946A-S FRONT PANEL ASS'Y 1
12-1 RGB0025-A TECHNICS BADGE 1
13 SHG1654 RUBBER 4
14 XTB3+10JFZ SCREW 11
15 XTB3+8JFZ SCREW 10
16 XTW3+15T SCREW 2
17 XTBS3+8JFZ1 SCREW 2
18 RGW0178-1S KNOB,MIC VOL. 1
19 RMN0582 HOLDER 1
20 REM0057 FAN UNIT 1 (GC)
21 XTB3+20JFZ SCREW 1
22 XTB3+8FFZ SCREW 1 (GC)
A1 RAK-EHA28WH REMOTE CONTROLLER 1
A1-1 RKK0123-H BATTERY COVER 1
A2 REE0393 SPEAKER CORD 2
A3 REE0984 SPEAKER CORD 2
A4 REE0985 SPEAKER CORD 2
A5 RJA0019-X AC POWER SUPPLY CORD 1
(GC)
A5 RJA0035-X AC POWER SUPPLY CORD 1
(GN)
A6 RQT5357-G OPERATING INSTRUCTIONS 1 (GC) / <IA>
A6 RQT5355-B OPERATING INSTRUCTIONS 1 (GN) / <IB>
A7 RQT5358-M OPERATING INSTRUCTIONS 1 (GC) / <IC>
A8 RQCB0169 SERVICE CENTER LIST 1
A9 RSA0006-J FM INDOOR ANTENNA 1
A10 RSA0022-J AM LOOP ANTENNA 1
A11 SJP5213-2 PLUG ADAPTOR 1
(GC)
