Technics SC-EH760 Service Manual

Ref. No. Part No. Part Name & Description Pcs Remarks
C927,28 RCE1HKA4R7BG 50V 4.7U 2
C931 ECA1CAK100XB 16V 10U 1
C961 ECEA1CKS100 16V 10U 1
CN601 RJU057W012 CONNECTOR(12P) 1
CN602 RJU057W008 CONNECTOR(8P) 1
CN603 RJU057W004 CONNECTOR(4P) 1
CN701-10 RJS1A1101T1 CONNECTOR(1P) 10
CN711-13 RJS1A1101T1 CONNECTOR(1P) 3 (GN)
CN714-20 RJS1A1101T1 CONNECTOR(1P) 7 (GC)
CN751 RJP1A4103 CONNECTOR(3P) 1 (GC)
CN781 RJS10T5ZA CONNECTOR(10P) 1
CN904 RJS4T5ZA CONNECTOR(4P) 1
CP101 RJT100W11 CONNECTOR(11P) 1
CP601 RJT057W012-1 CONNECTOR(12P) 1
CP602 RJT057W008-1 CONNECTOR(8P) 1
CP603 RJT057W004-1 CONNECTOR(4P) 1
D201 MA4056M DIODE 1
D306 SELS5223C LED 1
D500 MA165 DIODE 1
D551,52 MA165 DIODE 2
D553 MA700 DIODE 1 (GC)
D554 MA165 DIODE 1 (GC)
D555 MA4100M DIODE 1
D558 MA165 DIODE 1
D563 MA165 DIODE 1
D581-83 RL1N4003N02 DIODE 3 (GC)
D601,02 SB360L6508 DIODE 2
D607 1SS291TA DIODE 1
D613,14 MA165 DIODE 2
D657-59 MA165 DIODE 3
D701-04 1N5402BF DIODE 4
D705 RL1N4003N02 DIODE 1
D711 RL1N4003N02 DIODE 1
D715 MA165 DIODE 1
D717-20 RL1N4003N02 DIODE 4
D721 MA4300M DIODE 1
D723 MA4150M DIODE 1
D725 MA4082LTA DIODE 1
D730 MA4091H DIODE 1
D736 MA165 DIODE 1
D737 MA4082LTA DIODE 1
D738,39 MA165 DIODE 2
D740 MA165 DIODE 1 (GN)
D741,42 RL1N4003N02 DIODE 2
D743,44 RL1N4003N02 DIODE 1 (GN)
D745 MA4051M DIODE 1
D746 RL1N4003N02 DIODE 1
D747 MA4068H DIODE 1
(GC)
24
