Technics SL-PJ37A

we
obit
Ref.
No.
Removal
of
the
disc
holder
and
power|
Ref.
No.
Removal
of
the
loading
unit
6
switch
rod
7
Procedure
1—-2—5-6
A. Disc holder
1.
Pull
the
disc
holder
siowly
in
the
direction
of
the
arrow
until
the
disc
tray
comes
up.
2.
Pull
the
disc
holder
until
it
stops.
3.
Push
the
bracket
of
tray
SW
($1001)
in
the
direction
of
the arrow.
Pull out the disc holder further to remove it.
. Power switch rod
_ Set the power switch in the “OFF” position.
. Remove the power switch rod by using a screwdriver.
Now A
Bracket
of tray
SW(SIOO1)
Screwdriver |
Power Switch ||
Rod
Dise Tray
pos Checking of the servo P.C.B.
Procedure ;
+ 2-5 eWhen checking the soldered surface
— J—
of the servo P.C.B. and replacing the
parts, do as shown below.
Note: insert the loading unit into the tabs of the front
panel. (Fixed loading unit)
Secure the optical pickup assembly with a clip.
(Otherwise the clamper will interfere with the disc,
restricting turntable rotation.)
Servo PC.B.
Front Panel
Procedure
1+2+5+6-7
1. Remove the 3 screws (@~ @).
2. Remove the 3 connectors (CN12, CN401,
CN431).
ag
(To play a disc)
1. Place the test disc.
2. Reinstall the disc lid to the loading unit.
3. Turn “ON” the power switch of the player.
4. Push the bracket of tray SW ($1001) in the direction
of the arrow and release it.
Note: |f the test disc fails to rotate, press the tray switch
again.
Test Disc
\ Tray SW
(SI001)
Loading Unit
