e
How
to
remove
the
input
selector
P.C.B.
[Fig.
4]
1.
Remove
the
cabinet.
[See
Fig.
1]
Front
panel
2.
Remove
the
setscrew
[Fig.
4:
@®]
of
the
ground
wires.
3.
Remove
the
input
selector
P.C.B.,
release
the
claws
in
the
direction
of
arrow
(8),
and
pull
out
the
P.C.B.
toward
the
back
of
front
panel.
Input
selector
P.C.B.
Note:
Insert
a
input
selector
P.C.B.
into
the
guide.
Ground
wire
'
f
Nel
|
_
ide
[Nput
selector
guide|
|
guide
bcp.
aes
[Fig.
4]
e
How
to
remove
the
front
panel
and
sub-panel
ne
[Fig.
5]
Front
panel
==]
;
1.
Remove
the
3
set
screws
[Fig.5:
@
~
@]
on
the
i|
down
Sub-panel
chassis
next,
pull
out
the
front
panel
from
the
chassis.
2.
Release
the
5
claws
at
the
top
and
the
4
clows
at
the
down
of
the
sub-panel,
and
then
remove
the
front
panel
aslant
as
in
Fig.
5.
e
How
to
remove
the
each
switch
P.C.B.
attached
to
front
panel
[Fig.
6]
1.
Remove
the
cabinet.
[See
Fig.
1]
Power
switch
P.C.B.
2.
Remove
the
setscrew
[Fig.
6:
Q@]
of
the
ground
wires
and
then
remove
the
front
panel.
S&S
®
3.
To
remove
the
setscrew
[Fig.
6:
@]
and
remove
the
Front
panel
ae
power
switch
P.C.B.
ws
:
©
Speaker
4.
To
remove
the
speaker
selector
P.C.B.,
release
the
selector
P.C.B.
claw
in
the
direction
of
arrow
Os
and
pull
out
the
P.C.B.
toward
the
back
of
front
panel.
5.
To
remove
the
volume
P.C.B.,
release
the
claw
in
the
direction
of
arrow
(0),
and
pull
out
the
P.C.B.
toward
the
back
of
front
panel.
Note:
[XA,
PC]
areas
only
How
to
remove
the
power
switch
P.C.B.
To
remove
the
front
panel
and
remove
the
2
setscrews
on
the
front
of
sub-panel.
[Fig.
6]
