- The DISPAY can be removed from the top cabinet.
11.5. Removing the DISPLAY panel
1. Follow the item 11.4..
2. Remove the DISPLAY panel mounting screws ( 6 pcs.) as shown
in Fig.12 .
Fig.12
11.6. Removing the LCDL, LCDC and LCDR printed circuit boards
- Follow the item 11.5..
LCDL P.C.B.
- Remove the LCDL P.C.B. mounting screws ( 3 pcs.) as shown in
Fig.13 .
LCDC P.C.B.
- Remove the LCDC P.C.B. mounting screws ( 4 pcs.) as shown in
Fig.13 .
15
