*MAIN, CPL, CPR, JACK2, INVL, JACK, AS, ASUB, ACP, PKB, MKB1, MKB2 and NW in Remarks
indicate the Circuits and P. C. B.s. If the same Ref. No. is found in the replacement parts list,
check those indications in the Remarks.
*For U.S.A.
The marking <PASC> indicates that are supplied by Matsusita Electric Corporation of America
Panasonic Services Company , the others are supplied by SPC.
*For other destination except U.S.A.
Supply Factory for service parts marking *1 will be informal by suppliment after the decision.
Ref. No. Part No. Part Name & Description
Pcs
Remarks
1 5391092L7 TOP COVER (REAR SIDE) 1 <PASC> *1
2 400020 ADHESIVE BUMPON 3M 6 <PASC> *1
3 620016VZ GUIDE PIN FOR TOP COVER 1 <PASC> *1
4 090026VZ SUPPORT HOLDER (BRASS) 2 <PASC> *1
5 T983898L7RIC TOP COVER (FRONT SIDE) 1 <PASC> *1
5-1 QMFG1221AA FELT 2
5-2 QMFG1222AA FELT 1
6 T983897L7RIC SLIDE COVER 1 <PASC> *1
6-1 QGKG0095AA ORNAMENT 1
6-2 QMFG1258AA FELT 2
6-3 QMRG7031EC PROTECTOR 1
6-4 QMRG7032EC PROTECTOR 1
6-5 QMFG1259AA FELT 2
6-6 QMFG1260AA FELT 2
6-7 QMFG1262AA FELT 1
6-8 QMFG1261AA FELT 1
6-9 QXQG007AA AXLETREE 1
6-10 QMRG7056AA HOLDER 2
6-11 QWBG002AA HOLDER 1
7 5395137V7C TOP FRAME WITH CLOTH 1 <PASC> *1
8 79483125 PLASTIC WASHER 3 <PASC> *1
9 925330193 SCREW 3.5X30 (BLACK) 3 <PASC> *1
10 5391094V7C SPEAKER BOX TOP PANEL 1 <PASC> *1
11 925435293 SCREW 4X35 (BLACK) 18 <PASC> *1
12 T983899L7RIC PEDAL BOX 1 <PASC> *1
12-1 QMFG1286AA QRNAMENT 3
13 640028 ADJUSTER BOLT 2 <PASC> *1
14 QMBG009AA SPRING 3
15 QMFG1133AA FELT 3
16 QMFG1134AA FELT 3
17 QMWG4002AA PEDAL ARM 3
18 QMFG1135AA FELT 3
19 5396077L7 LONG & SHORT SUPPORT 1 <PASC> *1
20 150039 HINGE 1 <PASC> *1
21 925316297 SCREW 9 <PASC> *1
22 150042 HINGE FOR TOP COVER 1 <PASC> *1
23 XTT4+10A SCREW 37
24 XTB4+10B SCREW 2
25 XTT4+12AFZ SCREW 1
26 XTT4+14A SCREW 2
27 925335193T SCREW 3.5X35 (BLACK) 4 <PASC> *1
28 92541629D SCREW 4X16 (GOLD COLORED) 6 <PASC> *1
29
