Technics SX-PR1000 - Page 48

Ref. No. Part No. Part Name & Description
Pcs
Remarks
IP5 P6 ICP-N10T104 IC PROTECTOR 2
B1ZAZ0000035 AS
IP7 P8 ICP-N75T104 IC PROTECTOR 2
D4FA2R700001 AS
IP101 02 ICP-N10T104 IC PROTECTOR 2
B1ZAZ0000035 MAIN
JK1 QJJG010AA JACK HEADPHONE 1 1 JACK2
JK1 QJSG007AA PEDAL IN 1 JACK
JK1 SJVD0203B AC INLET 1
ACP
JK2 QJJG010AA JACK HEADPHONE 2 1 JACK2
JK2 QJSG018AA COMPUTER 1 JACK
JK3 QJJG011AA JKMIC 1 JACK2
JK3-K5 QJSG016AA MIDI THRU 3 K1CB103B0007 JACK
JK6-K9 QJJG003AA LINE OUT L 4 K2HB102J0037 JACK
JP1 ERJ6GEY0R00V CHIP JUMPER 1 MAIN
JP4 P6 ERJ6GEY0R00V CHIP JUMPER 2 MAIN
JP202 ERJ6GEY0R00V CHIP JUMPER 1 MAIN
JP301 02 ERJ6GEY0R00V CHIP JUMPER 2 MAIN
L1 ERDS2T0 0 1/4W 3 PKB
L1 QLBG005A COIL 1 G0ZZ00001936 MAIN
L1 QLQGT2T100SA 10UH X 2 1
G0B100Z00001 ACP
L1 QLQGT3T131TA 130UH X 3 1 G0B131Z00001 JACK2
L1 VLP0083 COIL 1 G0ZZ00001936 AS
L2 QLBG005A COIL 1 G0ZZ00001936 MAIN
L2 QLQGT3T131TA 130UH X 3 1 G0B131Z00001 JACK2
L2-L4 VLP0083 COIL 3 G0ZZ00001936 AS
L5 QLQGT3T131LA 130ÉHÅ~3 1 AS
L5 QLQGT3T131TA 130UH X 3 1 G0B131Z00001 JACK
L6 QLQGT1B800MA 80UH 1
G0C800Z00001 AS
L6 QLQGT3T131TA 130UH X 3 1 G0B131Z00001 JACK
L7 QLQGT1D600LA 60UHÅ~3 1 AS
L7 QLQGT3T131TA 130UH X 3 1 G0B131Z00001 JACK
L8 QLQGT1D600LA 60UHÅ~3 1 AS
L8 L9 QLQGT3T131TA 130UH X 3 2 G0B131Z00001 JACK
L10-13 QLQGT1B100MA 10UH 4 JACK
L14 QLQGT1B800MA 80UH 1 G0C800Z00001 JACK
L21 QLBG005A COIL 1 G0ZZ00001936 JACK
L101 QLBG005A COIL 1 G0ZZ00001936 MAIN
L201 QLQGT1T121LA COIL 1 MAIN
L202 QLBG005A COIL 1 G0ZZ00001936 MAIN
L203 QLQGT1T121LA COIL 1 MAIN
L204 QLBG005A COIL 1 G0ZZ00001936 MAIN
PCB1 SXPG235131 MAIN P.C.B. 1 MAIN <RTL>
PCB2 SXPG229731B JACK2 P.C.B. 1 JACK2 <RTL>
PCB3 SXPG2298181A AS PCB 1 AS <RTL>
PCB4 SXPG229821B ASUB P.C.B. 1 ASUB <RTL>
PCB5 SXPG229621A CPL P.C.B. 1 CPL <RTL>
PCB6 SXPG229751A CPR P.C.B. 1 CPR <RTL>
PCB7 SXPG229611C INVL P.C.B. 1 INVL <RTL>
PCB8 SXPG229911 JACK P.C.B. 1 JACK <RTL>
PCB9 SXPG218211 PKB P.C.B. 1 PKB <RTL>
48
