SYMBOL SPECIFICATION TYPE
Non-Polarized Electrolytic
Capacitors
ECEA_KN_type
Non-Polarized Electrolytic (for
Network system)
ECEA_Y_type
Tantalum Solid Electrolytic
Capacitors
ECS_type
Metallized Plastic Film Capacitors
(TF Series)
ECQV_type
Temperature Compensating
Ceramic Capacitors
ECC_type
High-Dielecytric Constant Ceramic
Capacitors
ECK_type, ECR_type
Axial Lead Ceramic Capacitors ECB_type
Metallized Polyester Film
Capacitors for Across the Line
ECQ_EW_type
Aluminum Electrolytic Capacitors
for Smoothing Circuit
ECES_type
Multilayer Ceramic Chip Capacitors ECUV_type
11. MEASURING CONDITION
11.1. Measuring condition of MAIN P.C.B.
Check Point 3 - 5
Set to the Self-diagnostic Mode followings.
- While pressing two E keys simultaneously, turn on the power
switch.
- SOUND : SOUND EXPLORER
- MAIN VOLUME: Max.
- Keyboard: A1
Check Point 1
Set to the Initial mode (refer to “OWNERS MANUAL ”).
