Technics SX-PR603

Ref. No. Part No. Part Name & Description Pcs Remarks
124 QMWG2006AA BLACK KEY 36
125 QMCG011BA SPRING 88
126 QMWG9027AA HAMMER(BLACK KEY) 8
127 QMWG9027AB HAMMER(BLACK KEY) 14
128 QMWG9027AC HAMMER(BLACK KEY) 7
129 QMWG9027AD HAMMER(BLACK KEY) 7
130 QMWG9025AA HAMMER(WHITE KEY) 12
131 QMWG9025AB HAMMER(WHITE KEY) 19
132 QMWG9025AC HAMMER(WHITE KEY) 11
133 QMWG9025AD HAMMER(WHITE KEY) 10
134 QMGG060AA RUBBER CAP(HAMMER) 88
135 QMWG8045AA KEY GUIDE 88
136 QMWG8041AA FUL CU RUM(4 PCS ON ONE) 1
137 QMWG8040AA FUL CU RUM(12 PCS ON ONE) 7
138 QMFG1267BA FELT 1
139 QMFG1268BA FELT 1
140 QMFG1266BA FELT 1
141 QMFG1265AA FELT 1
142 QMWG6020AA RUBBER SWITCH 1
143 QMWG6021AA RUBBER SWITCH 7
A1 QQFGPR703AA FAN BAG 1 P
A1 QQFGPR703BA FAN BAG 1 PC
A1 QQFGPR703CA FAN BAG 1 X XA EX EB XD XT XS GN
A1 QQFGPR703DA FAN BAG 1 EZ
A1 QQFGPR703EA FAN BAG 1 EF
A1 QQFGPR703FA FAN BAG 1 EG
A2 QJAG025AA AC CORD 1
P PC
A2 QJAG027AA AC CORD 1
X EX EZ EG EF XT XS
A2 QJAG028AA AC CORD 1
EB XD
A2 QJAG029AA AC CORD 1
GN
A2 QJAG031AA AC CORD 1
XA
A3 QFVG2014A FLOPPY DISK 1
A4 SJP5213-2 PLUG ADAPTOR 1
X XT
C1 ECA0JM102 1000UF 6.3V 1 INVL
C1 ECEA0JKA221 220UF 6.3V 1 CPL
C1 ECKCVA1472MF 4700PF LINE CAPACITOR 1
ACP
C1 ECKF1E473X 0.1UF 1 MKB1
C1 ECQE1A104M6 0.1UF 1
AS
C1 ECRF1H104ZF 0.1UF 1 PKB
C1 ECRR1H104ZF 0.1UF 1 JACK
C1 ECUV1H104ZFX 0.1UF 1 MAIN
C1 QCBG1H104ZFA 0.1UF 1 CPR
C1 QCBG1H473ZFA 0.047UF 1 JACK2
C2 ECBT1C222MR5 2200PF 1 CPL
C2 ECBT1C222MR5 0.0022UF 1 CPR
C2 ECCR1H221J5 220PF 1 JACK
C2 ECEA0JKA470 6.3V47U 1 MKB1
C2 ECOS1HP682D 6800UF 50V 1 AS
C2 ECQB1H473JF3 0.047UF 1 INVL
31
