Technics SX-PR603 - Page 48

Ref. No. Part No. Part Name & Description Pcs Remarks
L8,L9 QLQGT3T131TA 130UH × 3 2 JACK
L10-13 QLQGT1B100MA 10UH 4 JACK
L14 QLQGT1B800MA 80UH 1 JACK
L15 QLBG005A COIL 1 JACK
L101 QLBG005A COIL 1 MAIN
L201 QLQGT1T121LA COIL 1 MAIN
L202 QLBG005A COIL 1 MAIN
L203 QLQGT1T121LA COIL 1 MAIN
L204 QLBG005A COIL 1 MAIN
P1 QPGG0413AC PACKING CASE 1
P1 QPGG0413AD PACKING CASE 1 SX-PR603M
PCB1 SXPG235111 MAIN P.C.B. 1
PCB2 SXPG229711B JACK2 P.C.B. 1
PCB3 SXPG229811A AS P.C.B. 1
PCB4 SXPG229811B ASUB P.C.B 1
PCB5 SXPG229611B CPL P.C.B. 1
PCB6 SXPG229741A CPR P.C.B. 1
PCB7 SXPG229611C INVL P.C.B. 1
PCB8 SXPG229911 JACK P.C.B. 1
PCB9 SXPG218221 PKB P.C.B. 1
PCB10 SXPG231111A MKB1 P.C.B. 1
PCB11 SXPG231111B MKB2 P.C.B. 1
PCB12 SXPG230411 ACP P.C.B. 1
PCB12 SXPG230421 ACP P.C.B. 1
PCB12 SXPG230461 ACP P.C.B. 1
Q1 2SA830STP TRANSISTOR 1 CPL
Q1 2SA830STPB TRANSISTOR 1 CPR
Q1 2SA830STPB TRANSISTOR 1 CPR
Q1 2SA933STRS TRANSISTOR 1 JACK
Q1 2SB709ARTX TRANSISTOR 1 MAIN
Q1 2SC1815TPE2 TRANSISTOR 1 AS
Q1 2SD592ARS TRANSISTOR 1 INVL
Q2 2SA830STP TRANSISTOR 1 CPL
Q2 2SA830STPB TRANSISTOR 1 CPR
Q2 2SA933STRS TRANSISTOR 1 JACK
Q2 2SD2374 TRANSISTOR 1 AS
Q2 2SD592ARS TRANSISTOR 1 INVL
Q2 2SD601AQ TRANSISTOR 1 MAIN
Q3 2SA1015TPE2 TRANSISTOR 1 AS
Q3 2SA830STP TRANSISTOR 1 CPL
Q3 2SA830STPB TRANSISTOR 1 CPR
Q4 2SA830STP TRANSISTOR 1 CPL
Q4 2SA830STPB TRANSISTOR 1 CPR
Q4 2SB1548 TRANSISTOR 1 AS
Q5 2SA830STP TRANSISTOR 1 CPL
Q9 2SC1815TPE2 TRANSISTOR 1 AS
Q10,11 2SA1015TPE2 TRANSISTOR 2 AS
Q12 2SD592ARS TRANSISTOR 1 AS
Q13 2SB621ARS TRANSISTOR 1 AS
Q14 2SD592ARS TRANSISTOR 1 AS
Q15 2SB621ARS TRANSISTOR 1 AS
