Ref. No. Part No. Part Name & Description Pcs Remarks
X1 EFOEC4004T3 4MHz CERAMIC OSCILATOR 1 CPL
X1 EFOEC4004T3 4MHz CERAMIC OSCILATOR 1 CPR
X1 QSXG1A1600A 16MHZXTAL 1 MAIN
X101 QSXG2F2400A 24MHZ CERAMIC OSCILLATOR 1 MAIN
X201 QSXG1A2500A 25MHz QUARTZ OSCILLATOR 1 MAIN
X301 QSXG1A1693A X'TAL 1 MAIN
Z1 EXBA10E472J 4.7K × 4 1 MAIN
Z2-Z4 EXBV8V470J 47 × 4 3 MAIN
Z5,Z6 EXBA10E472J 4.7Kv4 2 MAIN
Z7,Z8 EXBV8V101J 100 × 4 2 MAIN
Z9 EXBA10E472J 4.7K × 4 1 MAIN
Z10 EXBS8V472J 4.7K × 4 1 MAIN
Z11 EXBV8V101J 100 × 4 1 MAIN
Z12-14 EXBA10E472J 4.7K × 4 3 MAIN
Z15 EXBV8V101J 100 × 4 1 MAIN
Z16 17 EXBA10E472J 4.7K × 4 2 MAIN
Z18 EXBS8V101J 100 × 4 1 MAIN
Z19,20 EXBS8V472J 4.7K × 4 2 MAIN
Z101 EXBV8V102J 1K × 4 1 MAIN
Z102-05 EXBS8V470J 47 × 4 4 MAIN
Z106 EXBS8V221J 220 × 4 1 MAIN
Z107 EXBV8V472J 4.7K × 4 1 MAIN
Z108 EXBS8V101J 100 × 4 1 MAIN
Z109 EXBV8V472J 4.7K × 4 1 MAIN
Z110 EXBV8V470J 47 × 4 1 MAIN
Z111 EXBV8V472J 4.7K × 4 1 MAIN
Z112 EXBA10E472J 4.7K × 4 1 MAIN
Z201,02 EXBV8V102J 1K × 4 2 MAIN
Z203 EXBV8V101J 100 × 4 1 MAIN
Z205 EXBV8V220J 22 × 4 1 MAIN
Z301-03 EXBV8V221J 220 × 4 3 MAIN
Z304 EXBS8V472J 4.7K × 4 1 MAIN
Z305 EXBS8V223J 22K × 4 1 MAIN
Z306 EXBS8V472J 4.7K × 4 1 MAIN
Z307 EXBS8V223J 22K × 4 1 MAIN
Z308,09 EXBV8V472J 4.7K × 4 2 MAIN
Z310 EXBS8V470J 47 × 4 1 MAIN
Z311-14 EXBV8V470J 47 × 4 4 MAIN
Z315-26 EXBV8V471J 470 × 4 12 MAIN
ZC101-04 ECJRVC1H470K 47PF × 4 4 MAIN
ZC105,06 ECJRVC1H101K 100PF × 4 2 MAIN
ZC303 ECJRVC1H101K 100PF × 4 1 MAIN
Notes:
*1: Since SW consists of buttons and P.C.B.s, we do not supply it as an individual part (refer to
“CABINET PARTS LOCATION ” on the next page).
17. CABINET PARTS LOCATION
