24
461306303 (A-000)
20
NOTE:
Hot Plate Ignition Failure
• Check alignment of burner holes to electrode.
• Check aeration sleeve for adjustment for gas type,
location and ambient conditions.
• No spark, check ignition box failure or power supply.
Before Leaving
• Check all connections for gas leaks with soap and
water. DO NOT use a naked fl ame for detecting
leaks. Ignite all burners to ensure correct operation
of gas valves, burners and ignition.
• Turn gas taps to low fl ame position and observe
stability of the fl ame. When satisfi ed with the cooker,
please instruct the user on the correct method of
operation.
• In case the appliance fails to operate correctly
after all checks have been carried out, refer to the
authorised service provider in your area.
6. INSTRUCTIONS FOR THE INSTALLER
GAS CONVERSIONS
When converting from Natural Gas to Propane ensure
that the NG regulator is removed and replaced with the
Test Point Assembly. An AGA Approved gas regulator
suitable for a supply pressure of 2.75kPa should be
part of the gas tank supply and the test point pressure
should be adjusted to 2.75kPa.
Replace the old data plate with one, which is suitable
for the type of gas for which the appliance has been
regulated.
REPLACING THE INJECTORS
Our burners can be adapted to different types of gas by
simply installing the injectors suitable for the gas you
want to use. To help the installer, the table on page 28
gives the burner nominal heat input, injector diameter
and operating pressure of the different gas types.
Comply with the following instructions:
Injector replacement - Hob burners.
To change the injectors on the hob, remove the burner
cup and head and with a 7 mm Ø socket spanner
replace them (fi g. 20).
After having replaced the injectors, it will be
necessary to proceed with burner adjustment as
explained in the previous paragraphs.
