14
A
B
C
D
L
N
M
E
H
G
L
J
USB USB port
HDMI 1 HDMI input
HDMI 2 HDMI input
HDMI 3 HDMI input
VGA(PC) VGA-PC input
VGA(PC) Audio In 3.5mm PC audio input
CI CARD IN Common Interface Card Input
SCART SCART input
COAX Audio Out Digital Coax output
COMPONENT (HD) Component input (YPbPr)
VIDEO Video input
R/L (AUDIO) Video / Component audio input
RF IN RF / TV Aerial Input
HEADPHONES 3.5mm Headphone output
A
B
C
D
E
F
G
H
I
J
K
NM
Connecting a DVD Player/Recorder, Video Recorder or
Cable/Satellite Box
TVs Input/Source should be set to SCART
Connections
RF I N
SCART
TV Aerial
Wall Socket
SCART
OUT
RF
IN
RF
OUT
DVD or V CR
F
K
I
