Y Pb/Cb Pr/Cr
AUDIO
L R
COMPONENT IN
S-VIDEO 1
SAV IN
SCART1(RGB)
SCART2(AV)
FRONT PANEL CONTROLS AND CONNECTION OPTIONS
5
Front control panel
1. HDMI input
2. PC input
3. COMPONENT input
4. Earphone output
5. SCART input
6. S-VIDEO input
7. PC audio input interface
Note: 1. Do not connect both AV and SCART2 at the same time.
2. Do not connect both S-VIDEO2 and VIDEO at the same time.
3. Do not connect both COMPONENT and S-VIDEO1 at the same time.
4. When SCART1 and SCART2 is input at the same time, SCART2 is prior.
6
PREPARATION FOR REMOTE CONTROL
3
2
1
Remote control installation
1. According to the figure display below, place the remote control with face down,
then open the cover of the battery apartment.
2. As in the figure display below, install two AAA batteries. (The + and - symbol of
battery must match with the marks on the remote).
3.Close the cover of the battery apartment.
Cautions for using remote control:
Confirm there is no object between the
remote control and the remote sensor
of TV set.
Sunshine or other strong light will
interfere with the signal sent by the
remote control. In this situation turn
the TV set to avoid the direct light
source.
Do not put the remote control in direct
heat or a damp place, or potential
damage to the remote may occur.
Please use two AAA 1.5V batteries.
Do not mix battery types.
Install the batteries as the correct
polarities.
Do not use rechargeable batteries.
If your TV is to be stored for a period
of time, remove the batteries from
the remote control.
Menu button
Source button
Program down/up button
Volume down/up button
Standby button
Power indicator
Remote sensor
AUDIO
VIDEO
R
L
S-VIDEO2
ANT IN
MENU
VOL+
VOL-
CH+
CH-
1 2 3
4
5
6
7
