TechniSat DIGIT S3 DVR User Manual

77
DE
EN
3.7 Optional accessories
Optional IsiZapper Remote Control
The IsiZapper (Item No. 0000/3773) is an optional remote control that is specially
designed for operation in the ISI mode (see Section 13).
TechniSat A/V Adapter Kit
For connecting analogue audio/video playback devices, please use the TechniSat
specific adapter kit, Item No. 0000/3649.
4 Connecting the DVB receiver
4.1 Mains connection
The digital receiver should only be connected to the mains power supply once you
have finished making all the connections to the various other components. This
will prevent damage to the digital receiver or other components.
> Once you have made all the connections in accordance with the following
sections, use the power supply unit supplied to connect the receiver to a
230 V/50-60 Hzmains power outlet.
4.2 Sat system
> Connectthe antennas input RF IN (4) on the digital receiver to your external
unit using a suitable coaxial cable.
Also note Section 7.6 (antenna configuration) in your instruction manual.
It is not possible to receive analogue TV!
4.3 Connecting to a TV
> Connect the receiver (HDMI output 7) and TV (HDMI input) using an HDMI cable.
If your television set is appropriately equipped, it will switch to the HDMI
input automatically when the digital receiver is switched on. Optionally,
you can also connect the receiver to the TV set via analogue. Please note
Section 4.7.
4.4 Hi-Fi/surround amplifier
To achieve the best possible sound quality, you can connect your digital receiver to
a hi-fi/surround sound amplifier.
Digit S3 DVR_V2.indd 77Digit S3 DVR_V2.indd 77 23/02/2022 08:5323/02/2022 08:53

TechniSat DIGIT S3 DVR Specifications

General

Tuner type	Digital
Demodulation	QPSK
Product color	Black
Number of tuners	1 tuner(s)
Audio output channels	- channels
On Screen Display (OSD)	Yes
Electronic Program Guide (EPG)	-
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2
Package weight	994 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	6.2 W
Video codecs	H.264
Cables included	HDMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Signal source	Cable, Ethernet (RJ-45), Satellite
Digital signal format system	DVB-S, DVB-S2

Weight and Dimensions

Depth	130 mm
Width	180 mm
Height	44 mm
Weight	380 g
