TechniSat DIGIT S3 DVR User Manual

84
5.4 Changing a seing
You can create seings using the Arrow selection, the Selection list, by entering
numbers and by using the virtual keyboard. The device specifies the method that
can be used to change a highlighted seing. This is evident from the following
displayed symbols:
- Arrow selection (Section 5.4.1)
Arrows are shown on the le- or right-hand edge of the highlight.
- Selection list (Section 5.4.2)
The symbol is shown at the right-hand edge of the highlight.
- Numerical input (Section 5.4.3)
- Virtual keyboard (Section 5.4.4)
The symbol is shown at the right-hand edge of the highlight.
5.4.1 Arrow selection
> If shown to the le and right next to the set value, you can alter this
using the le/right arrow keys.
5.4.2 Selection list
If is shown on the right next to the set value, the value is altered via the
selection list.
> Press the OK key to open the selection list.
Digit S3 DVR_V2.indd 84Digit S3 DVR_V2.indd 84 23/02/2022 08:5323/02/2022 08:53

TechniSat DIGIT S3 DVR Specifications

General

Tuner type	Digital
Demodulation	QPSK
Product color	Black
Number of tuners	1 tuner(s)
Audio output channels	- channels
On Screen Display (OSD)	Yes
Electronic Program Guide (EPG)	-
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2
Package weight	994 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	6.2 W
Video codecs	H.264
Cables included	HDMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Signal source	Cable, Ethernet (RJ-45), Satellite
Digital signal format system	DVB-S, DVB-S2

Weight and Dimensions

Depth	130 mm
Width	180 mm
Height	44 mm
Weight	380 g
