TechniSat DIGIT S3 DVR User Manual

88
The various numeric keys are assigned the following displayed leers, numbers,
characters and symbols.
0:
1:
2:
3:
4:
5:
6:
7:
8:
9:
Once you have reached the field you want with the highlight, you can
then begin selecting the next character immediately since, in this case,
the character is added directly to the term. If you wish to continue
directly selecting a character from the same numeric pad, you can add
the previously highlighted character to the term by pressing the right
arrow key.
5.5 Option selection
In some menus and operating modes (e.g. TV mode, music/images playback etc.),
you have the option of calling up additional functions and options via the options
selection function.
> Pressing the Option key opens the option selection at the lower right-hand
corner of the screen.
In this example the Option selection menu for the channel list is shown.
> Each additional press of the Option key moves the highlight down one line
at a time.
Digit S3 DVR_V2.indd 88Digit S3 DVR_V2.indd 88 23/02/2022 08:5323/02/2022 08:53

TechniSat DIGIT S3 DVR Specifications

General

Tuner type	Digital
Demodulation	QPSK
Product color	Black
Number of tuners	1 tuner(s)
Audio output channels	- channels
On Screen Display (OSD)	Yes
Electronic Program Guide (EPG)	-
Digital Satellite Equipment Control (DiSEqC)	1.0, 1.2
Package weight	994 g
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 75 %
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (typical)	6.2 W
Video codecs	H.264
Cables included	HDMI
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Signal source	Cable, Ethernet (RJ-45), Satellite
Digital signal format system	DVB-S, DVB-S2

Weight and Dimensions

Depth	130 mm
Width	180 mm
Height	44 mm
Weight	380 g
