TechniSat DIGITRADIO Car 2 User Manual

58
Note: Insert the microphone cable securely to ensure that it is connected fully and correctly.
2. To ensure that the microphone cable is not in the way when you are positioning the reception unit, clamp the
microphone temporarily so that it is in the driver’s vicinity. For example, you can mount the microphone on the driver’s
sun visor.
4.5 Positioning the reception unit
1. Choose a position for the reception unit as far up the windscreen as possible, and at least 4 cm from the side of the
screen. Make sure that the reception unit and antenna do not impair the driver’s view.
2. If possible, carefully pull away the roof lining at the front until there is a slight gap.
3. Pull the magnetic earth through the gap with the silver magnet pointing upwards. Make sure that the magnet makes
contact with the metal chassis of the vehicle.
4. Clean the selected section of the windscreen with a cleaning cloth and let it dry.

TechniSat DIGITRADIO Car 2 Specifications

General

Dimmable	Yes
Projection	No
Product color	Black
On Screen Display (OSD) languages	DAN, DEU, DUT, ENG, FRE, ITA, NOR
Radio type	Car
Tuner type	Digital
FM band range	87.5 - 108 MHz
DAB III band range	174 - 240 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	20
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
Apple docking compatibility	Not supported
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Display type	LCD
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	5 - 90 %
Compatible memory cards	MicroSD (TransFlash)
Battery voltage	3.7 V
Battery capacity	800 mAh
Compatible battery sizes	AAA
Number of batteries supported	2
Power source	Cigar lighter
Package depth	63 mm
Package width	157 mm
Package height	308 mm
Package weight	550 g
RMS rated power	- W

Weight and Dimensions

Depth	31 mm
Width	76 mm
Height	60 mm
Weight	64 g
