Technotherm TTS 200 - Technical Data

15 Edition:12/16
Manual Storage Heater TTS with electronic control
Technical datas standard flat models
Modell
(incl. ECO-devices)
TTS 170 F
TTS 260 F
TTS 340 F
TTS 430 F
TTS 510 F
Type
THS 038
THS 039
THS 040
THS 041
THS 042
Article No.
852 317 005
852 326 005
852 334 005
852 343 005
852 351 005
Nominal rating *
1700 W
2550 W
3400 W
4250 W
5100 W
Nominal voltage
230V~
400 V 2N~
400 V 3N~
50 Hz
400 V 3N~ 50 Hz
Nominal charge
period*
8 h
Nominal charge
13,6 kWh
20,4 kWh
27,2 kWh
34,0 kWh
40,8 kWh
Maximum charge
15,1 kWh
22,7 kWh
30,2 kWh
37,8 kWh
45,3 kWh
Dimensions (mm)
width
height
deep
580
660
185
760
660
185
940
660
185
1120
660
185
1300
660
185
Weight total
108 kg
155 kg
206 kg
255 kg
303 kg
Weight cabinet
26 kg
31 kg
40 kg
47 kg
54 kg
No. Brick packs
4 x 44
2 x 45
6 x 44
3 x 45
8 x 44
4 x 45
10 x 44
5 x 45
12 x 44
6 x 45
Fan
230 V / 50 Hz / 1 x 9 W
230 V / 50 Hz / 2 x 9 W
Power ZH
750 W
1000 W
1000 W
1500 W
1500 W
*
Power ratings with full rated power
Connections according to the connection possibilities (see page 19)
Model (incl. Eco-devices)
TTS 170 F
TTS 260 F
TTS 340 F
TTS 430 F
TTS 510 F
100 % (default)
1700 W
2550 W
3400 W
4250 W
5100 W
92 %
-
-
3130 W
3910 W
4690 W
84 %
-
-
2860 W
3570 W
4280 W
75 %
-
-
2550 W
3190 W
3820 W
67 %
1140 W
1710 W
-
-
-
50 %
850 W
1270 W
-
-
-
