TecLime TWC-51 - Reverse the Door Swing

12
Reverse the door swing
Remarks:
The instruction is based on a unit with right door hinge installed already.
To reverse the door from right hinge to left hinge, you need to get ready 2 new spare parts: an
upper left hinge, and a bottom left hinge.
All removed parts must be saved to do the door reinstallation, except those remarked with
“Disused”.
1
Open the door, and loosen the 2 screws ① and ②. See Figure 1.
2
Carefully remove the door from the upper right hinge ④ and prevent it from
scratching. Take out the support rod ③ from the door hinge hole. See Figure 2.
3
Pull out the 6 decorating plastic bolts covering the reserved hinge screw holes at the
front left corner of the cabinet
4
Unscrew the upper right hinge ○,4(Disused) and bottom left hinge ○,6 (Disused) from
the cabinet. See Figure 3.
Install the upper left hinge ○,7and bottom left hinge○,8 to the left side of the cabinet.
Make sure that the screws are tightened. See Figure 4.
5
Put upside down the door and install it to the left hinges by following the opposite
steps of taking down of the door as described above.
6
Cover the hinge screw holes on the right side with the 6 decorating plastic bolts
