Electrical wire
Control panel must be connected as follow:
red + black - = battery
brown + black - = outlet pump
blue + black - = inlet pump (single) or electrovalve (centralized)
grey - black - = holding tank sensor
See also electricalwires drawings.
Supply cables size :
up to 10 metres, section 4 mm.
more than 10 metres, section 6 mm.
Do not substitute supplied plugs.
Connect a 40 A fuse on the red + black wire.
Operating
Control panel with one switch
With one switch control panel, inside the ceramic bowl there is always a little quantity
of water.
Pushing the button, the toilet automatically flush and clear out.
Control panel with two switches
Our toilet with two switches control panel has been studied to remain absolutely
empty when it is not used.
Before using, the bowl is automatically filled so ceramic surface with never be dirty
from organic residuals.
After use the bowl is automatically flushed and cleared out.
Operating instructions:
a) before use press "before use" button
b) after use press "after use" button
