Tecnam P2006T - Page 194

Page 7 - 12
Section 7 – Airframe and Systems description
PEDESTAL CONTROLS
4
th
Edition, Rev 0
4. PEDESTAL CONTROLS
Following picture shows the controls installed on the central pedestal.
Figure
7.
– Pedestal controls
No
Description
1 and 2
Choke control
3
Choke friction knob
4
Upper levers friction knob
5-6
LH and RH Throttle lever
7-8
LH and RH Carburetor Heating lever
9-10
LH and RH Propeller Pitch Control lever
11
Parking brake
12
Windshield defrost control knob
