TIMER Operation
1. Press the TIMER ON button. The remote
control shows TIMER ON, the last Auto-on
setting time and the symbol "H" will be shown
on the LCD display window. Now it is ready to
reset the Auto-on time to START the operation.
2.
3.
Push the TIMER ON button again to set desired
Auto-on time. Each time you press the button,
the time increases by half an hour between 0
and 10 hours and by one hour between 10 and
24 hours.
After setting the TIMER ON, there will be a one
second delay before the remote control transmits
the signal to the air conditioner. Then, after
approximately another 2 seconds, the symbol "H"
will disappear and the set temperature will re-
appear on the LCD display window.
Press the TIMER ON button to select the auto-
on time for the unit. Press the TIMER OFF
button to select the auto-off time for the unit.
To set the Auto-on time.
To set the Auto-off time.
1. Press the TIMER OFF button. The remote
controller shows TIMER OFF, the last Auto-off
setting time and the symbol "H" will be shown on
the LCD display window. Now it is ready to reset
the Auto-off time to stop the operation.
2. Push the TIMER OFF button again to set desired
Auto-off time. Each time you press the button, the
time increases by half an hour between 0 and 10
hours and by one hour between 10 and 24 hours.
3. After setting the TIMER OFF, there will be a one
second delay before the remote controller
transmits the signal to the air conditioner. Then,
after approximately another 2 seconds, the
symbol "H" will disappear and the set temperature
will re-appear on the LCD display window.
MODE
FAN
TEMP
SLEEP FRESH
LED FOL LO W ME
TURBO SEL F CLEAN
ON/OFF
TIMER
ON
TIMER
OFF
!
CAUTION
When you select the timer operation, the remote controller automatically transmits the
timer signal to the indoor unit for the specified time. Therefore, keep the remote
controller in a location where the indoor unit can receive the signal. The effective
operation time set by the remote controller for the timer function
is limited to the following settings: 0.5, 1.0, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0,
5.5, 6.0, 6.5, 7.0, 7.5, 8.0, 8.5, 9.0, 9.5, 10, 11, 12, 13, 14, 15,16,17, 18, 19, 20,
21, 22, 23 and 24.
Example of timer setting
Start
Off
6 hours later
(Auto-on Operation)
The TIMER ON feature is useful when you want
the unit to turn on automatically before you return
home. The air conditioner will automatically start
operating at the set time.
To start the air conditioner in 6 hours.
1. Press the TIMER ON button, the last setting of
starting operation time and the symbol "H" will
show on the display area.
2. Press the TIMER ON button to display "6.0H "
on the TIMER ON display on the remote
control.
3. Wait for 3 seconds and the LCD display area
will show the temperature again. The
"TIMER ON" indicator remains on and this
function is activated.
TIMER ON
Example:
Set
9
10
To Next Page
