STEP n.
5
Unscrew the white cap and
remove it from the top of the
exchanger
(img.19)
Place the heater inside the
exchanger (img.21). Don’t forget
the nylon washer (img.20).
Screw very well the ring nut
(img.22)
Connect the heater to the cable
assembly that you find in the grey
or red fan support (img.23)
www.tecoonline.com | www.tecous.com
19 20
21 22 23
NYLON
WASHER is different from
EPDM
GASKET
