13
T2612 UNI
TECSYSTEM S.r.l ®
CUTOUT
GALVANIZED SHEET IRON
Thickness 1.2 mm
FRONT VIE
W
Cut out: 155 X 280 mm
Screw rivet M3 x 15mm
Screw rivet
M3 x 15mm
Screw rivet
M3 x 15mm
190 mm
210 mm
150 mm 150 mm
320 mm
Screw rivet
M3 x 15mm
Screw rivet
M3 x 15mm
Screw rivet M3 x 15mm
