T2612 UNI
TECSYSTEM S.r.l ®
N° KEYS EFFECT NOTES
1 PRG/SET
Keep pressed PRG key until PRG-ON led turns on.
After PRG indication,
it appears ALARM threshold for CH U-V-W
Program LED will light
2 Enter the desired Alarm setpoint
3 PRG/SET TRIP set T° appears
4 Enter the desired Trip setpoint
5 PRG/SET Led CH 4 blinks Enabling CH 4
6 Load YES or NO
YES: CH 4 connected
NO: CH 4 disconnected
11 PRG/SET
Led Fan blinks and channel leds
o which fan is referred turn on
12 Select NO, CH U-V-W or CH 4 (if CH 4 YES)
NO: disabled fan,
Goes to point 21
13 PRG/SET Display shows ON FAN1 turning on
14 PRG/SET It appears ON threshold for FAN1
15 Load desired threshold
16 PRG/SET Display shows OFF FAN1 turning off
17 PRG/SET It appears OFF threshold for FAN1
18 Load desired threshold
to set up FAN2 repeat the same procedure as FAN1
19 PRG/SET Display shows HFn
Fan cyclic test for 5 minutes each
“n” hours
20 Load desired number of hours 000= disabled function
21 PRG/SET Fcd appears on display
22 Enter Fcd YES or NO
Fcd YES= control of damaged
Pt100 connected
23 PRG/SET Hld appears on display HLd YES = HOLD feature enabled
24 Enter HLd YES or NO
25 PRG/SET PRG appears on display
Prg NO= program cannot be
changed
26 set up Prg YES or NO
27 PRG/SET
Adr appears on display
ONLY for T2612 and T2612-AD,
not for T2612-B and T2612-C
28
enter the address of the unit
29 PRG/SET
on display appears bdr
30
enter the desired Baud rate
Possible Baud rates:
2.4k-4.8K-9.6K-19.2K
(8 bit, Stop=1 cannot be changed)
31 PRG/SET
Par appears on display Parity bit setting
32
enter the desired Parity bit
No= not parity bit
Odd= Odd parity bit
Eve= Even parity bit
33 PRG/SET Display shows END Programming end
34 ENT Loaded data storage and programming exit
Err: wrong programming for
values indicated by leds (note 2)
35
ENT
PRG/SET
Programming is completed.
Press ENT to return to normal operating mode
The unit will perform
the light test
7 PRG/SET CH4 Alarm setpoint appears
8 Enter the desired Alarm setpoint
9 PRG/SET CH4 Trip setpoint appears
10 Enter the desired Trip setpoint
20) PROGRAMMING
