1. Display
2. On / Off button
3. Increase temperature control
4. Decrease temperature control
5. Mode control
6. Fan speed control
7. Timer control
8. Cooling mode indicator
9. Dehumidifier mode indicator
10. Air circulation mode indicator
11. Reservoir full indicator
12. High fan speed indicator
13. Low fan speed indicator
14. Timer setting indicator
15. Remote control receiver
Insert the plug into the wall outlet.
Press the
-button B to switch on the air conditioner.
• If the ambient temperature is higher than 25ºC, the unit will work in
cooling mode.
• If the ambient temperature is < 25ºC, the unit will work in air circulation
mode.
With
-button 5 you can change the operating mode of the unit.
By pressing the
-button the following modes appear:
Cooling mode H
Dehumidifying mode I
Air circulation mode J
