Service Manual
SPA WASHING MACHINES (TKD)
Service Manual: MSWM15043 EN - 11 -
Motor (not inverter)
Check the next:
Terminals 5-10: 1.3 ohm.
Terminals 8-9: 3.15 ohm.
Terminals 6-7: 0.25 ohm.
Terminals 3-4: 48 ohm.
Motor (inverter)
Cannot be checked
Pressure switch
This is an electronic one so it cannot be directly
checked directly. It is possible to check its performance
in option “t06” into the service menu.
