Technical Specifications
Dimension (h x w x d) — 6-5/8" x 7-9/16" x 2-13/16" (170 x 193 x 72mm)
Weight — 2.9 lbs (1.3 Kg)
Ambient — 30 to 120°F (0 to 50°C), < 95% RH non-condensing
Power supply — 24Vac ± 10%, 60Hz, 3VA class II
Relay capacity — SPST, 24Vac, 10 Amps
Sensors — Sensor 071, Outdoor Sensor 070. Accurate with up to 500 feet (150m) 18AWG cable
Control accuracy
— ± 1°F (± 0.5°C)
This electronic control does not exceed the Class B limits for radio noise emissions from digital apparatus as set out in the Radio Interference Regulations of the Canadian
Department of Communications. Le présent numérique n'émete pas de bruits radioeléctriques dépassant les limites applicables aux appareils numériques de Classe B
prescrites dans le réglement sur le brouillace radioeléctrique édicté par le Ministére des Communications du Canada.
Features
11 Indicator lights — Power, Heat Demand, DHW Demand, WWSD, Unoccupied, Min. Supply, System Pump, DHW Pump, Stage 1, Stage 2, Test
System pump output —
Isolated SPST relay contacts close when heating is required
DHW pump output —
Isolated SPST relay contacts close on DHW Demand
Stage 1 & 2 output — Isolated SPST relay contacts close to operate each stage
Test button — Initiates and controls pre-programmed test run
Error message display — Sensor faults are indicated by flashing light codes
Settings
Heating Curve — 0.4 to 3.6
DHW temperature — 80 to 200°F (27 to 93°C)
Minimum Supply — Off, 80 to 170°F (Off, 27 to 77°C)
Boiler Differential — 2 to 42°F (1 to 23°C)
Occupied — 35 to 105°F (2 to 41°C)
Unoccupied — 35 to 105°F (2 to 41°C)
Stage 1 switch — To switch Stage 1 off or into operating mode
Stage 2 switch — To switch Stage 2 off or into operating mode
Rotate switch — To allow boilers to rotate firing sequence based on hours of use
DHW Unoccupied switch — Generation/No generation of DHW during Unoccupied mode
DHW Priority switch — To make generation of DHW have priority over heating operation
DHW valve/pump switch — Selected for the type of device used when generating DHW
Heat Demand switch — External 24Vac signal or permanent internal signal
Zone Control/Sensor switch — Input from tekmar Zone Control or Indoor Sensor 074
