REVERSE BEND
(Shown aligned for a 90˚ reverse bend)
Reference
mark
Bend
mark
R
L
0
0
0
4
5
9
0
13
5
18
0
page 4
FIG. 4
Sometimes it is necessary to bend tubing
in a reverse position. For a 90˚ reverse
bend, the BEND mark must align with the
"R" line on roll guide. Complete bending
procedure described on page 3.
BEND
