Tektronix AFG3021 Service Manual

Troubleshooting
AFG3000 Series Arbitrary/Function Generators Service Manual 6-31
--- Diagnostics ---
2100 Calibration data not found A72
2101 Calibration data checksum A72
2102 Calibration data invalid A72
2201 ASIC1 memory failure A1x/A3x/A4x
2202 ASIC2 memory failure A12/A32/A42
2203 ASIC1 Overheat A1x/A3x/A4x
2204 ASIC2 Overheat A12/A32/A42
--- Output Diagnostics ---
2301 CH1 Internal offset failure A1x/A3x/A4x
2302 CH2 Internal offset failure A12/A32/A42
2303 CH1 Output offset failure A1x/A3x/A4x/A51/A61
2304 CH2 Output offset failure A12/A32/A42/A51/A61
2305 CH1 Output gain failure A1x/A3x/A4x/A51/A61
2306 CH2 Output gain failure A12/A32/A42/A51/A61
2401 CH1 x3dB attenuator failure A1x/A3x/A4x
2402 CH2 x3dB attenuator failure A12/A32/A42
2403 CH1 x6dB attenuator failure A1x/A3x/A4x
2404 CH2 x6dB attenuator failure A12/A32/A42
2405 CH1 x10dB attenuator failure A1x/A3x/A4x
2406 CH2 x10dB attenuator failure A12/A32/A42
2407 CH1 x20dB 1 attenuator failure A1x/A3x/A4x
2408 CH2 x20dB 1 attenuator failure A12/A32/A42
2409 CH1 x20dB 2 attenuator failure A1x/A3x/A4x
2410 CH2 x20dB 2 attenuator failure A12/A32/A42
2411 CH1 Filter failure A51/A61
2412 CH2 Filter failure A51/A61
2413 CH1 x20dB 3 attenuator failure A43
2501 CH1 Sine Flatness failure A1x/A3x/A4x/A51/A61
2502 CH2 Sine Flatness failure A12/A32/A42/A51/A61
Table 6-4: Error codes (cont.)
Error code Description Related module
