Tektronix AFG3021 Service Manual

Specifications
AFG3000 Series Arbitrary/Function Generators Service Manual 1-7
✔Spurious
1
(non harmonic) (at 1 V
p-p
amplitude) page 4-32
AFG3011 10 Hz ≤ frq < 1 MHz: < –60 dBc
1 MHz ≤ frq ≤ 10 MHz: < –50 dBc
AFG3021B, AFG3022B 10 Hz ≤ frq < 1 MHz: < –60 dBc
1 MHz ≤ frq ≤ 25 MHz: < –50 dBc
AFG3101, AFG3102 10 Hz ≤ frq < 1 MHz: < –60 dBc
1 MHz ≤ frq < 25 MHz: < –50 dBc
25 MHz ≤ frq ≤ 100 MHz: –50 dBc + 6 dBc/oct
AFG3251, AFG3252 10 Hz ≤ frq < 1 MHz: < –50 dBc
1 MHz ≤ frq < 25 MHz: < –47 dBc
25 MHz ≤ frq ≤ 240 MHz: –47 dBc + 6 dBc/oct
Phase noise, typical (at 1 V
p-p
amplitude)
AFG3011 10 MHz: < –110 dBc/Hz at 10 kHz offset
AFG3021B, AFG3022B,
AFG3101, AFG3102,
AFG3101, AFG3102
20 MHz: < –110 dBc/Hz at 10 kHz offset
Residual clock noise, typical
AFG3021B, AFG3022B,
AFG3011
–63 dBm
AFG3101, AFG3102,
AFG3251, AFG3252
–57 dBm
Square wave page 4-35
✔Rise time/fall time
AFG3011 ≤ 50 ns
AFG3021B, AFG3022B ≤ 18 ns
AFG3101, AFG3102 ≤ 5ns
AFG3251, AFG3252 ≤ 2.5 ns
Jitter (rms), typical
AFG3021B, AFG3022B,
AFG3011
500 ps
AFG3101, AFG3102 200 ps
AFG3251, AFG3252 100 ps
Table 1-9: Output characteristics (cont.)
Characteristics Description PV reference
page
