Performance Verification
4-18 AFG3000 Series Arbitrary/Function Generators Service Manual
AFG3000 Series
Performance Test Record
Minimum Test result Maximum
Rise-Fall Time
AFG3011
CH1 Rise Time Amplitude: 1.0 V
pp
- - - - - 50 ns
Fall Time Amplitude: 1.0 V
pp
- - - - - 50 ns
Rise Time Amplitude: 10.0 V
pp
- - - - - 50 ns
Fall Time Amplitude: 10.0 V
pp
- - - - - 50 ns
AFG302xB
CH1 Rise Time Amplitude: 1.0 V
pp
- - - - - 18 ns
Fall Time Amplitude: 1.0 V
pp
- - - - - 18 ns
Rise Time Amplitude: 10.0 V
pp
- - - - - 18 ns
Fall Time Amplitude: 10.0 V
pp
- - - - - 18 ns
CH2 Rise Time Amplitude: 1.0 V
pp
- - - - - 18 ns
Fall Time Amplitude: 1.0 V
pp
- - - - - 18 ns
Rise Time Amplitude: 10.0 V
pp
- - - - - 18 ns
Fall Time Amplitude: 10.0 V
pp
- - - - - 18 ns
AFG310x
CH1 Rise Time Amplitude: 1.0 V
pp
- - - - - 5 ns
Fall Time Amplitude: 1.0 V
pp
- - - - - 5 ns
Rise Time Amplitude: 10.0 V
pp
- - - - - 5 ns
Fall Time Amplitude: 10.0 V
pp
- - - - - 5 ns
CH2 Rise Time Amplitude: 1.0 V
pp
- - - - - 5 ns
Fall Time Amplitude: 1.0 V
pp
- - - - - 5 ns
Rise Time Amplitude: 10.0 V
pp
- - - - - 5 ns
Fall Time Amplitude: 10.0 V
pp
- - - - - 5 ns
