Operating basics
8. To change the frequency
value, use the keypad
and Units beze
l buttons.
For example, if you enter
a value "2" using the
keypad, the b
ezel menus
will automatically change
to Units.
After enter
ing the
frequency value, push
the Units bezel button
or the front
-panel Enter
button to complete the
entry.
You can cha
nge the
Amplitude, Phase, and
Offset values in the same
way.
9. You c an also change the
frequenc
y value using
the general purpose knob
and the arrow keys.
To incre
ase the value,
turn the knob clockwise.
To change a specificdigit,
select
it by pushing the
arrow keys. Then change
it by turning the knob.
Quick Tips
Use the front-panel shortcut buttons to quickly select a waveform parameter.
You can also specify a waveform parameter by using bezel menu selection.
This method does not use the front-panel shortcut buttons.
When you specify a waveform parameter using the shortcut buttons or bezel
menu selec t ion, an a ctive parameter is displayed in green in the graph area.
AFG3000 and AFG3000C Series User Manual 43
