Operating basics
3. In this page, y
ou can set
the parameters for center
frequency, frequency
span, hold tim
e and
select the sweep type.
Hold time represents the
amount of tim
e that the
frequency must remain
stable after reaching the
stop freque
ncy.
Push the -m o re- button
to display the second
sweep menu.
4. In this page, you can
select the
sweep mode
(Repeat or Trigger) and
trigger source.
5. This is a sample
oscilloscope screen.
Thetopisasampleofa
sweep waveform.
6. This is a trigger output
signal.
Quick Tips
For frequency sweep, you can select a sine, square, ramp, or arbitrary
waveform. Pulse, DC, and Noise waveforms cannot be selected.
Once the sweep is selected, the fre quency is swept from the sweep start to
the sweep stop frequencies.
If a start frequency is lower than a stop frequency, the instrument sweeps from
the low frequency to the high frequency.
AFG3000 and AFG3000C Series User Manual 57
