Speciﬁcations

Table 16: System characteristics (cont.)

Characteristic Description

Amplitude change 90 ms 97 ms 90 m s

Select user Arbitrary

waveform is 4K points

(USB memory)

48 ms 50 ms 49 ms

Select user Arbitrary

waveform is 128K points

(USB memory)

260 ms 266 ms 240 ms

Data download, typical

4000 points Arb waveform data (8 Kbytes)

GPIB: 320 ms

USB: 47 ms

LAN: 78 ms

Acoustic noise, typical < 50 dBA

Weight (approximate) 4.5 kg (9.92 lb)

Dimensions

Refer to the following illustrations.

20 AFG3000C and AFG3000 Series Speciﬁcations and Performance Veriﬁcation
