Tektronix AFG3102

Performance verification
Rise/Fall Time Test Record (cont.)
Rise Time Amplitude: 10.0 Vpp
-----
5ns
Fall Time Amplitude: 10.0 Vpp
-----
5ns
CH2
Rise Time Amplitude: 1.0 Vpp
-----
5ns
Fall Time Amplitude: 1.0 Vpp
-----
5ns
Rise Time Amplitude: 10.0 Vpp
-----
5ns
Fall Time Amplitude: 10.0 Vpp
-----
5ns
AFG3151C / 3152C
CH1
Rise Time Amplitude: 1.0 Vpp
-----
3.5 ns
Fall Time Amplitude: 1.0 Vpp
-----
3.5 ns
Rise Time Amplitude: 10.0 Vpp
-----
3.5 ns
Fall Time Amplitude: 10.0 Vpp
-----
3.5 ns
CH2
Rise Time Amplitude: 1.0 Vpp
-----
3.5 ns
Fall Time Amplitude: 1.0 Vpp
-----
3.5 ns
Rise Time Amplitude: 10.0 Vpp
-----
3.5 ns
Fall Time Amplitude: 10.0 Vpp
-----
3.5 ns
AFG325x / 325xC
CH1
Rise Time Amplitude: 1.0 Vpp
-----
2.5 ns
Fall Time Amplitude: 1.0 Vpp
-----
2.5 ns
Rise Time Amplitude: 5.0 Vpp
-----
2.5 ns
Fall Time Amplitude: 5.0 Vpp
-----
2.5 ns
CH2
Rise Time Amplitude: 1.0 Vpp
-----
2.5 ns
Fall Time Amplitude: 1.0 Vpp
-----
2.5 ns
Rise Time Amplitude: 5.0 Vpp
-----
2.5 ns
Fall Time Amplitude: 5.0 Vpp
-----
2.5 ns
50 AFG3000C and AFG3000 Series Specifications and Performance Verification
