Tektronix AFG3000 Series Function Generator Guide v1.0 Portland State University
12
Example #2
Define a pulse waveform with the following properties:
Frequency = 1 MHz, Duty = 10%, High = 5 V, Low = 0 V, t
LE
= 25 ns, t
TE
= 15 ns
Two possible setups (either one would work):
Buttons to push
Type
Pulse FB
Frequency/Period/Delay Menu BB
Frequency BB
1 NK
MHz BB
IB
Amplitude/Level Menu BB
High Level BB
5 NK
V BB
Low Level BB
0 NK
V BB
IB
Pulse Parameter Menu BB
Duty BB
10 NK
% BB
Leading Edge BB
25 NK
ns BB
Trailing Edge BB
15 NK
ns BB
Buttons to push
Type
Pulse FB
Frequency/Period/Delay Menu BB
Period BB
1 NK
µ s
BB
IB
Amplitude/Level Menu BB
High Level BB
5 NK
V BB
Low Level BB
0 NK
V BB
IB
Pulse Parameter Menu BB
Width BB
0.1 NK
µ s
BB
Leading Edge BB
25 NK
ns BB
Trailing Edge BB
15 NK
ns BB
