Tektronix AWG5204

Performance tests
Performance Test Minimum Test result Maximum
AWG5202, AWG5204, AWG5208
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch1–
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch2–
–2 V –2.05 V –1.95 V
AWG5204, AWG5208
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch3–
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch4–
–2 V –2.05 V –1.95 V
AWG5208
Offset
2V 1.9
5V
2.0
5V
0 V –10 mV 10 mV
Ch5–
–2 V –2.05 V –1.95 V
Offset
2
V
1
.95 V
2
.05 V
0 V –10 mV 10 mV
Ch6–
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch7–
–2 V –2.05 V –1.95 V
Offset
2 V 1.95 V 2.05 V
0 V –10 mV 10 mV
Ch8–
–2 V –2.05 V –1.95 V
72 AWG5200 Series Technical Reference
