Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
Analog DC Bias Accuracy
(AC Direct Output Path)
AWG5202, AWG5204, AWG5208
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch1+
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch2+
–5 V –5.12 V –4.88 V
AWG5204, AWG5208
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch3+
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 m
V
20 mV
Ch4+
–5 V –5.12 V –4.88 V
AWG5208
DC Bias
5 V 4.88 V 5.12 V
0V –2
0mV
20
mV
Ch5+
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch6+
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch7+
–5 V –5.12 V –4.88 V
DC Bias
5 V 4.88 V 5.12 V
0 V –20 mV 20 mV
Ch8+
–5 V –5.12 V –4.88 V
AWG5200 Series Technical Reference 75
