Tektronix AWG5204

Performance tests
Performance test Minimum Test result Maximum
CH6:1
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH6:2
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH6:3
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH6:4
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH7:1
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525
V
–0.475
V
CH7:2
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH7:3
+1.5
5V
1.37
V
1.73
V
0.0
V
–25
mV
25 m
V
–500 mV –0.525 V –0.475 V
CH7:4
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV +25 mV
–5
00 mV
–0
.525 V
–0
.475 V
C
H8:1
+ 1.55 V 1.37 V 1.55 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH8:2
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH8:3
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
CH8:4
+ 1.55 V 1.37 V 1.73 V
0.0 V –25 mV 25 mV
–500 mV –0.525 V –0.475 V
84 AWG5200 Series Technical Reference
