Tektronix CFG253 User Manual

Appendix A: Specifications
10
CFG253 User Manual
Table 2: Warranted Characteristics (Cont.)
Characteristic Measurement
Sawtooth linearity
20 Hz to 200 kHz 99%
200 kHz to 3 MHz  97%
Square response  100 ns rise/fall time maximum output into
50
W load
Main output amplitude
Two ranges:
0-20ĂVĂpeakĆtoĆpeak
100ĂmV to 20ĂV
pĆp
(open circuit)
50ĂmV to 10ĂV
pĆp
(50ĂW load)
0-2ĂV peakĆtoĆpeak
10ĂmV to 2ĂV
pĆp
(open circuit)
5ĂmV to 1ĂV
pĆp
(50ĂW load)
Impedance
50 W ±10%
DC offset <–10 V to >+10 V (open circuit), and
<–5 V to >+5 V (into 50
W load)
Duty cycle
5
:1
mi
n
im
u
m
du
t
y cyc
le
c
ha
n
ge
(50% at Center:Cal position), with symmetry button (Freq
 10) pushed in
Sweep rate Continuously variable from 0.5 to 50 Hz
Sweep width Variable from 1:1 to 100:1
Table 3: Physical Characteristics
Characteristic Dimension
Width 240 mm (9.46 in)
Height 64 mm (2.53 in)
Depth 230 mm (9.o in)
Weight 2.0 kg (4.4 lb)
