Tektronix MSO2000B Series Programmer's Manual

Commands Listed in Alphabetical Order
Related Commands
MEASUrement:R
EFLevel:METHod, MEASUrement:IMMed:TYPe,
MEASUrement:MEAS<x>:TYPe
Arguments
<NR3> is the low reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:REFLEVEL:ABSOL UTE:LOW 0.0 sets the low r eference level
to 0.0 V.
MEASUREMENT:REFLEVEL:ABSOL UTE:LOW? might return
:MEASUREMENT:REFLEVEL:ABSO LUTE:LOW 0.0000E+00 indicating
that the absolute low reference level is set to 0.0 V.
MEASUrement:REFLevel:ABSolute:MID[1]
Sets or returns the mid reference level, and is the 50% reference level when
MEASUrement:REFLevel:METHod is set to Absolute. This command affects the
results of period, frequency, delay, and all cyclic measurements.
NOTE. this command affects the associated reference level parameter for all
MEASurements:IMMed and the four periodic measurements.
Group
Measurement
Syntax
MEASUrement:REFLevel:ABSol ute:MID[1] <NR3>
MEASUrement:REFLevel:ABSol ute:MID[1]?
Related Commands
MEASUrement:REFLevel:METHod
Arguments
<NR3> is the mid reference level, in volts. The default is 0.0 V.
Examples
MEASUREMENT:REFLEVEL:ABSOL UTE:MID 1 .71 sets the mid reference level
to 0.71 V.
MEASUREMENT:REFLEVEL:ABSOL UTE:MID? might return
:MEASUREMENT:REFLEVEL:ABSO LUTE:MID 0.7100E+00 indicating
that the absolute mid1 reference level is set to 0.71 V.
MSO2000B, DPO2000B, MSO2000 and DPO2000 Series Oscilloscopes Programmer Manual 2-209
