Commands Listed in Alphabetical Order
10000 : WFMINPR
E:PT_FMT Y :WFMINPRE :XUNIT "s" :WFMINPRE:XINCR
4.0000E-9 :WFMINPRE:XZERO 0.0000 :WFMINPRE:PT_OFF 0
:WFMINPRE:YUNIT "V" :WFMINPRE:YMULT 4.0000E -3 :WFMINPRE:YOFF
0.0000 :WFMINPRE:YZERO 0.0000 DATA:DESTINATION REF1
DATA:ENCDG RIBINARY DATA:SOURCE CH1 DATA:START 1 DATA:STOP
10000 D ATA:WIDTH 1 :DATA:RESOLUTION FULL :DATA:COMPO SITION
COMPOSITE_
YT
NOTE. The TEKSecure command can take up to five minutes to complete. The
oscilloscope is inoperable during this period.
Group
Miscellaneous
Syntax
TEKSecure
Examples
TEKSECURE initializes bo
th waveform and setup memories.
This is a program example of how to generate an SRQ when
TEKSECURE
completes:
# Bit 0 of the DESE (Device Event Status Enable Register)
# enables OPC to be repor
ted to the SESR (Standard Event
# Status Register)
DESE 255
# Bit 0 of the ESER (Event Status Enable Register)
# enables OPC to be summarized in the ESB (Event Status #
Bit) of the SBR (Status Byte Register)
*ESE 255
# Bit 5 of the SRE (Service Request Enable Register)
enables
# the generation of SRQ when the ESB bit of the SBR
becomes # TRUE
*SRE 32
TEKSECURE;*OPC
When the TEKSECURE operation has completed, the OPC bit of the SESR will be
TRUE and SRQ will h
ave been generated.
TIME
Sets or returns the time that the oscilloscope displays.
Group
Miscellaneous
2-292 MSO2000B, DPO2000B, M SO2000 and DPO2000 Series Oscilloscopes Programmer Manual
